Pressure Controllers
The brand-new 7XX series of pressure controllers offers unprecedented speed and accuracy. These controllers, which are designed with cutting-edge technology, enable personnel to monitor and manage pressure using responsive and user-friendly touchscreen interfaces, bringing calibration laboratory operations to previously unheard-of levels of efficiency and precision. These controllers raise the standard for precise instrumentation with their quick-swap pressure modules and pressure ranges of up to 15,000 PSI.
Additel 773
Pressure Controller / Generator
- Pressure ranges from -380 inH2O (-0.95 bar) to 400 inH2O (1 bar)
- Two removable internal pressure modules0.02%FS accuracy
- Control stability of 0.003%FS
- Ultra-High speed pressure generation and control
- Optional barometric pressure module
- Built-in differential pressure pump
- Large 7″ color touch screen display
- Multi-automatic test functions:pressure switch, test, leak test, PSV test, etc.
- Modular design for easy maintenance, greatly reducing on-site downtime
Additel 783
Pressure Controller
- Pressure ranges from -14.35 psi (-0.99 bar) to 6000 psi (420 bar)
- Two removable internal pressure modules with multi-range selection
- 0.02% FS, 0.01% FS, and 0.011% RD accuracies available
- Control stability of 0.003%FS
- Ultra-High speed pressure control
- Absolute and Gauge Pressure
- WiFi enabled communications
- Large 7″ color touch screen display
- Optional barometer module
- Easy-to-use icon driven interface
- I/O alarm
Additel 793
Pressure Controller/Generator
- Maximum pressure control range to 15,000 psi (1,000 Bar)
- Interchangeable pressure module
- Oil and water versions available
- Accuracy of 0.02%FS, 0.01%FS or 0.01%RD
- Dual-range from -15~3,000 psi (-1~200 Bar ) to 0~15,000 psi (0~1,000) Bar
- Control stability 0.005%FS
- Ultra-High speed pressure generation and control
- No external pressure source required
- Control using internal or external pressure modules
- Contamination Prevention System (CPS) (ADT793 optional)
- LAN, USB, RS232, and Ethernet communication
- External reservoir support
- Easy maintenance
- Emulation mode
Pressure Calibrators
Additels range of pressure calibration tools has been painstakingly designed to provide accuracy, speed, and dependability in every application. Whether you want an advanced calibrating reference gauge (673 and 273Ex) or fully self-contained pressure production (760, 761A, 762), all of their pressure calibrators include user-friendly features and programs that will boost productivity and require less equipment.
Additel 762W
Automated Hydraulic Pressure Calibrator
- Automated pressure generation and control to 15,000 psi (1035 Bar)
- Accuracy to 0.01%FS
- Dual-range with a manual or auto-selected mode
- Designed for use with deionized water
- Control stability ≤ 0.005%FS
- Portable – designed for use in the field and in the lab
- Supports two external pressure modules
- Wi-Fi, LAN, Bluetooth, USB and Ethernet communication
- Full HART field communicator
- HART and profibus communication
- Data logging and task management
- Patented electric pump technology
- ISO 17025-accredited calibration w/data included
Additel 762
Automated Hydraulic Pressure Calibrator
- Automated pressure generation and control to 15,000 psi (1035 Bar)
- Accuracy to 0.01%FS
- Dual-range calibration
- Control stability ≤ 0.005%FS
- Portable – designed for use in the field and in the lab
- Control by external pressure modules
- Supports two external pressure modules
- Wi-Fi, LAN, Bluetooth, USB and Ethernet communication
- Full HART field communicator
- HART and profibus communication
- Data logging and task management
- Patented electric pump technology
- ISO 17025-accredited calibration w/data included
Additel 761A
Automated Pressure Calibrator
- Automated and self-contained pressure generation and control to 1500 psi (100 bar)
- Standard accuracy models as low as 0.01%FS
- Two removable internal pressure modules for multi-range selection (Single pressure module for barometric)
- Control stability to 0.003%FS or 0.02 hPa
- Portable, designed for use in the field and in the lab
- Ability to measure two external pressure modules
- Wi-Fi, Bluetooth, USB and Ethernet communication
- HART and profibus communication
- Data logging and task management
- Patented electric pump technology and improved speed
- ISO 17025-accredited calibration w/data included
Additel 673
Advanced Digital Pressure Calibrators
- Pressure ranges up to 60,000 psi (4,200 bar)
0.02%, 0.05% FS or 0.1% RD Accuracy - Color Touchscreen Display
- Every model measures Gauge or Absolute Pressure
- Built-in Barometer
- Intuitive Smartphone Like Interface
- Bluetooth and USB Communication
- Wi-Fi (optional)
- Measure mA or V, and with 24V loop power
- Full HART Field Communicator (Optional)
- Data logging
- Communicates with Additel’s Link Mobile App
- ISO 17025-accredited calibration w/data included
Additel 273Ex
Handheld Pressure Calibrator
- 0.02%, 0.05% FS Accuracy
- Intrinsically Safe
- Field Switchable Pressure Module
- Dual Digital Pressure Module Inputs
- Color Touchscreen Display
- Built-in Quick Test Task Feature
- Built-in Barometer
- Intuitive Smartphone Like Interface
- Bluetooth and USB Communication
- Optional HART Communication
- Communicates with Additel’s Link Mobile App
- ISO 17025-accredited calibration w/data included
